* Patented products

* Led brand :Cree XTE

* Power supply :Meanwell

* Lamp luminous efficiency between 70-75lm/w

* 40watt to 150watt available

* Fresnel optical design for PC cover brings perfect light distribution

* The lamp can be separated into two parts Jeds is on one part, other components such as power supply are inside the other part, with this structure #we can assemble the lamp faster and easier.

* Beam angle : 90xl35deg

* IP65 for outdoor usage

LED TECHNICAL DATA

Typical Luminous Flu&Efficience @350mA;

• 130lm@25°C

Max Junction Temperature:

• 150C

Color Temperature:

3500K-6500K

LED life Cycle

• 50,000 hrs.

LUMINAIRE TECHNICAL DATA

LED light source

24pcs XTE CREE (40/60W)

36pcs XTE CREE (80W)

48pcs XTE CREE (100W)

60pcs XTE CREE (120/150W)

Luminous Flux :

40W-3200 lm

60W-4800 lm

80W-6400 lm

100W-8000 lm

120W-9600 lm

150W-12000 lm

Housing Material :

• Die Cast Aluminum with durable

polyester powder coating & PC Front lens

Operating Temperature :

-30℃~+45℃

Power Dirver:

AC:100~295Vac 50/60Hz

Classification :

■IP66 Class I

Wall Junction mounting

Net Weight:

40W/60W: 4.5kg

80W/100W: 4.5kg

120W/150W: 8kg

COMPLIANCE STANDARD

Driver

UL7CUL,CE,PSE,EN61347

Luminaire:

CE,ROHS,PSE

APPLICATION

Exterior building Lighting Pedestrain Walkway

Note: Specifications are subject to change without prior notice.
