Main Features
1. Advanced all-digital control
Machine with CPU control, all the operational parameters of UPS are controlled by the CPU, ensuring the UPS is in the best working condition. Improved the accuracy of the product parameter, ensured full compliance of product performance, the product failure rate effectively reduce.
2. Intelligent Charger
Built-in smart charger, with TOP charge type (charging type of high current at the initial, and balanced type and floating type alternating charging), shorten the battery charging time, extend the battery life, and it is suit to the areas of high rate power cut.
3. Wide input voltage range (110V-300V)
Interactive structural design, low frequency type program, with superior shock resistance. To satisfy the demand for different type of load, this might be widely used in household, commercial, industrial, outdoor base station.
4. Special Protection method
IN Series takes muti-level protection mode of output, which could resisit the impact effectively, and also with the short circuit protection function, which could enhance its reliability.
5. Well unattended function
When the main power is abnormal, the battery will supply power instead till low-voltage appeared, and then UPS shut down; when the main power come back, the UPS will start working automatically, and it will charge for the battery at the same time. No need to turn on the UPS manually.
6. High Efficiency and Energy Saving
When AC power is normal, the inverter is under dormant status, the main power through the built-in voltage regulator (AVR) directly to supply power to the loads, and its efficiency is as high as 98%. Therefore it is called “Green UPS” which in full compliance with the spirit of low carton.
