LED high mast floodlight differ greatly from the typical street or roadway lights. High Mast Lighting are regularly mounted at 60 ft to more than 100 ft above ground level and occasionally as high as 250 ft. Normal street lights are typically mounted at heights lower than 60 ft, and many are in the 30 ft range.

The applications for LED high mast floodlight where the illumination of extremely large areas such as transportation terminals , airports, high speed interchanges, prisons, ports, rail yards and freight terminals ,other large ,outdoor maintenance or storage yards and specialty roadway applications.

The LED high mast floodlight allow you to replace existing Metal Halide , High Pressure Sodium, Mercury Vapor High Mast light fixtures with energy efficient LED products.Energy savings can be as much as 70％ or more when coupled with energy saving controls, and will provide high quality, high intensity lighting.

Features:

Compliance stds: iEC/EN 60598-2-1

Power from 240 to 960 watt

AC 80-265V, 50/60 Hz

Beam Angle: 20 º /40 º /60 º /90 º /120 º

High efficiency output up to 150 Lm per watt

Robust Aluminium structure & mounting bracker,

PF>0.95

RA>80

IP 66 Rating

Extra SPD 20KV option

5 years warranty

Innovation advantage :

1.Unique cooling fins enhance heat dissipation transmission

2.Available in horizontal & vertical array for each modules

3.Adjustable irradiation angle for single LED modules

4.Light transmittance of PC lens more than 90%

5.IP 68 cable gland to insure each module reliable connection
