Branch Circuits
|
|
Indoor Enclosure-NEMA Type 1
|
|
Ampere
Rating
|
Max.
1 'Pole
|
No. Of Circuits
|
Max.
1/2 ” Pole
|
Front
Type
|
Catalog
Number
|
Dimensions(mm) Height Width Depth
|
|
40
|
2
|
2
|
4
|
Surface
|
|
|
|
85
|
|
125
|
4
|
4
|
8
|
Combination
|
HPE2-04125C
|
235
|
185
|
80
|
|
125
|
6
|
6
|
12
|
Surface
|
HPE2-06125S
|
280
|
285
|
85
|
|
125
|
6
|
6
|
12
|
Surface, with door
|
HPE2-06125SD
|
280
|
285
|
85
|
|
125
|
6
|
6
|
12
|
Flush
|
HPE2-06125F
|
280
|
285
|
85
|
|
125
|
6
|
6
|
12
|
Flush,with door
|
HPE2-06125FD
|
280
|
285
|
85
|
|
125
|
8
|
8
|
16
|
Surface
|
HPE2-08125S
|
280
|
285
|
85
|
|
125
|
8
|
8
|
16
|
Surface,with door
|
HPE2-08125SD
|
280
|
285
|
85
|
|
125
|
8
|
8
|
16
|
Flush
|
HPE2-08125F
|
280
|
285
|
85
|
|
125
|
8
|
8
|
16
|
Flush,with door
|
HPE2-08125FD
|
280
|
285
|
85
|
|
125
|
12
|
12
|
24
|
Combination
|
HPE2-12125C
|
490
|
360
|
97
|
|
200
|
16
|
16
|
32
|
Combination
|
HPE2-16200C
|
520
|
360
|
97
|
Notes: S- surface mounting F- flush mounting C-combination surface/flush
<!--[if !supportLists]-->* <!--[endif]-->If covert to main breaker, add ”M” for example,HPE2-06125F to HPE2-06125FM
<!--[if !supportLists]-->* <!--[endif]-->Interiors are sold separately.
Click Download
